28-34HRC Hot Rolled Plastic Mould Steel Plate PDS-3 P20 1.2311 3Cr2Mo Thickness 10-300mm

Guangzhou Changfeng Steel Co., LTD
Contact Now

28-34HRC Hot Rolled Plastic Mould Steel Plate PDS-3 P20 1.2311 3Cr2Mo Thickness 10-300mm

  • 1
  • 2

Brand Name : CF STEEL

Model Number : P20 1.2311 1.2312 1.2738 P20+Ni PDS-3

Certification : ISO/Mill Certificate

Place of Origin : China

MOQ : 3MT

Price : USD580-725/ MT

Payment Terms : L/C, T/T

Supply Ability : 3000t/Month

Delivery Time : 7-30 days

Packaging Details : standard export packing or customers' request.

Standard : DIN,ASTM,AISI,GB,JIS

Surface treatment : Black / Milling / Machined

Hardness : HRC28-34

Test : SGS / Ut 100% / Element Testing

Technology : Forged or Hot Rolled

sharp : round plate flat

thickness : 8-700mm

width : 155-2400mm

Length : 6000-10000mm

dia : 10-300mm

HS CODE : 722540 & 722830

Sample : Free sample

Contact Now

1.2311 P20 3Cr2Mo PDS-3 Special Alloy Steel Plastic Mould Steel Plate

1: 3Cr2Mo 1.2311 P20 steel introduction
AISI P20 Steel Plate Material is a versatile, low-alloy tool steel that is characterized by good toughness at moderate strength levels. The special purpose mold steel P20 steel plate is commonly used for plastic injection mold cavities and tooling and for die casting dies for zinc. P20 mold steel plate material is typically sold in the pre-hardened condition at a hardness of approximately 300 HBW.
2: P3Cr2Mo 1.2311 P20 Steel equivalent

Country USA German GB/T
Standard ASTM A681 DIN EN ISO 4957 GB/T 1299
Grade P20 1.2311 3Cr2Mo


3: P3Cr2Mo 1.2311 P20 steel chemical composition

Grade C Si Mn P S Cr Mo
P20 0.28-0.4 0.2-0.8 0.6-1 0.03 0.03 1.4-2 0.3-0.55
1.2311 0.35-0.45 0.2-0.4 1.3-1.6 0.03 0.03 1.8-2.1 0.15-0.25
3Cr2Mo 0.28-0.4 0.2-0.8 0.6-1 0.03 0.03 1.4-2 0.3-0.55


4: P3Cr2Mo 1.2311 P20 steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the sales.

5: P3Cr2Mo 1.2311 P20 steel overviews

Available Size (mm) Thickness/Diameter Width Length
Plate 8-460 1600-2200 4000-10000
Round 12-120 / 4000-6000
Block 250-800 800-1600 2000-6000

Heat treatment Normalized ; Annealed ; Quenched ; Tempered
Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
Payment terms T/T;L/C
Trade terms FOB; CIF; C&F; etc..
Delivery time 1) For abundant stock, 7-15 days.
2) For customized products, 15-30 days.

6: P3Cr2Mo 1.2311 P20 Delivery condition
For hot forged bar, usually the delivery condition is hot forged, annealed/QT rough turned/Black surface.
For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
For hot forged plate, usually the delivery condition is hot forged, annealed/QT, milled surface
For hot rolled plate, usually the delivery condition is hot rolled, annealed/QT, black surface.

3Cr2Mo 1.2311 P20 Hot Rolled Forged Plastic Mould Steel
28-34HRC Hot Rolled Plastic Mould Steel Plate PDS-3 P20 1.2311 3Cr2Mo Thickness 10-300mm28-34HRC Hot Rolled Plastic Mould Steel Plate PDS-3 P20 1.2311 3Cr2Mo Thickness 10-300mm

About Us
Guangzhou Changfeng Steel Co., Ltd. is a professional special steel company, which specializing in this line in China since 2005. Our main products are Plastic Mould Steel, Hot Work Mould Steel, Cold Work Mould Steel, Alloy Structural Steel, Tool Steel, Stainless Steel, Carbon Steel and Forged Block.
To ensure provide high quality products to customers, we have close cooperation with many Chinese first class special steel enterprises, including Baosteel Group, Dongbei Special Steel, Changcheng Special Steel, Hongsheng Heavy Industry, Xingcheng Special Steel and Daye Special Steel.
